Through the development of THE FREEFALL LIFEBOAT the crew can abandon their ship or platform, safely and quickly. Even when exposed to the most extreme conditions, such as fire or being full of water, the freefall lifeboat has proven to be a lifesaving appliance that could withstand the most stringent safety demands.The FREEFALL LIFEBOAT concept is acknowledged to be one of the most important improvements in the field of SAFETY at SEA. Since then many ships and offshore platforms worldwide have been equipped with Freefall Lifeboats.

Range of FFLB & capacities:

Type Length Breadth Capacity Range as per DNV Empty Boat weight* Loaded boat weight Drop height from bow Cradle weight Equipment weight FFLB & Cradle system
FL25 8.50 m. 2.55 m. 6-12 4.250 kg 5.450 kg 22.10 m. 4.500 kg 8.750 kg
FL30 9.50 m. 2.90 m. 6-16 5.100 kg 6.700 kg 31.50 m. 5.400 kg 10.500 kg
FL50 11.25 m. 3.50 m. 16-32 9.200 kg 12.400 kg 31.50 m. 20.000 kg 29.200 kg
FL60 13.50 m. 4.00 m. 32-50 15.000 kg 20.000 kg 40.00 m. 22.000 kg 37.000 kg
FL75 15.00 m. 4.40 m. 50-70 19.000 kg 26.000 kg 40.00 m. 23.500 kg 42.500 kg

Materials:

The use of ALUMINIUM Alloys as basic materials for a freefall lifeboat has many advantages:

The most suitable material to withstand the forces and loads involved with the freefall drop

  • Compared to GRP  it does not lose its original strength even
    after 20 years of extensive use
  • High strength to weight-ratio
  • Long duration of life
  • Corrosion resistant
  • Minimum of maintenance required
  • Nontoxic and recyclable

Freedom of design and easy to fabricate
